Shurflo 9300 Series Solar Water Pumping Kit System up to 120 feet (No top of pole mount)

Shurflo 9300 Series Solar Water Pumping Kit - 120-feet, NO Pole Mount

---

This Shurflo 9300 Series Solar Water Pumping Kit System can pump 1.68 gallons per minute at a max of 120', lower head distances will increase flow rate (see table below). If you'd like to check out this similar kit but with a solar panel pole mount go here Shurflo 9300 Solar Water Pumping Kit - 120-Feet With Pole Mount

Kit Details:

• Shurflo 9300 Submersible Pump
• Shurflo 9300 series 902-100 (LCB-O) pump controller
• 1 x 120w 24v solar panels

Note: The 902-100 (LCB-O) pump controller must be mounted in a dry location.

For water pump cable please see the following links 10/2 without ground. We recommend the 902-200 (LCB-G)controller for solar water pumping systems with a battery bank since a system with the 902-100 (LCB-O) would require an additional charge controller if a battery bank was required.

Additional Pre-designed Shurflo 9300 Kits

• Shurflo 9300 Series Solar Water Pumping Kit System up to 120 feet With Pole Mount

• Shurflo 9300 Series Solar Water Pumping Kit System up to 230 feet With Pole Mount

• Shurflo 9300 Series Solar Water Pumping Kit System up to 230 feet No Pole Mount

SolarLand 120w 24v Polycrystalline Off Grid Solar Panel SLP120-24U

Shurflo 9300 Series 24v Solar Pump Controller 902-100 (LCB-O)

Shurflo 9300 Submersible Solar Water Well Pump 12 - 24 VDC 9325-043-101

Array Direct Performance (24V array)
Vertical lift	Minimum solar array size	Flow rate (gpm)	Amps @ 30V
20	2 x 32 watts	1.95	1.5
40	2 x 32 watts	1.90	1.7
60	2 x 50 watts	1.81	2.1
80	2 x 50 watts	1.76	2.4
100	2 x 50 watts	1.71	2.6
120	2 x 50 watts	1.68	2.8
140	2 x 80 watts	1.65	3.1
160	2 x 80 watts	1.63	3.3
180	2 x 80 watts	1.55	3.6
200	2 x 80 watts	1.52	3.8
230	2 x 80 watts	1.36	4.1
