Introducing the Victron Energy SmartSolar MPPT 150/60-Tr Charge Controller (Model SCC115060211), a high-performance solar charge controller designed to optimize energy harvest and maintain battery health in residential, commercial, and off-grid solar energy systems. With its cutting-edge MPPT technology and advanced features, it ensures efficient power management and long-term reliability.

Key Features:

• Ultra-Fast Maximum Power Point Tracking (MPPT): Continuously adjusts to the optimal voltage and current levels, maximizing energy extraction from your solar panels, even in partially shaded or variable light conditions.
• Advanced Maximum Power Point Detection: Detects and locks onto the optimal power point during partial shading scenarios, ensuring maximum energy harvest.
• Bluetooth Smart Built-In: Monitor and configure your system wirelessly using the VictronConnect app on your smartphone, tablet, or computer.
• Wide Battery Compatibility: Supports 12V, 24V, and 48V battery systems with automatic detection and optional software selection for 36V systems.
• Comprehensive Protections: Includes safeguards against over-temperature, PV reverse polarity, PV short circuit, and PV reverse current, ensuring safe and reliable operation.
• Optional SmartSolar Control Display: Add an external display for on-device system monitoring and performance insights.
• Global Remote Monitoring: Compatible with the Victron Remote Management Portal (VRM) and GlobalLink 520, providing real-time data and control for installations with or without internet access.
• Battery Recovery Functionality: Capable of recharging severely depleted batteries (down to 0 volts) as long as the cells are not permanently damaged.

Product Overview:

The SmartSolar MPPT 150/60-Tr is engineered to ensure your solar energy system operates at peak efficiency. Its ultra-fast MPPT technology enables maximum energy harvest from solar panels, significantly outperforming traditional charge controllers in dynamic light conditions such as intermittent cloud cover.

Integrated Bluetooth connectivity allows for easy monitoring and configuration through the VictronConnect app, empowering users to optimize system performance and troubleshoot issues remotely. For installations requiring remote or global access, the controller integrates seamlessly with the Victron VRM Portal, enabling comprehensive system management from anywhere in the world.

The battery recovery function ensures reliability even in critical scenarios, allowing the controller to recharge batteries that have been deeply discharged to 0 volts, provided they are not permanently damaged.

Its robust design includes extensive protections, ensuring safe operation under challenging conditions. Whether you’re powering a residential setup, an off-grid installation, or a commercial application, the SmartSolar MPPT 150/60-Tr provides the efficiency, flexibility, and reliability needed for modern solar energy systems.

Applications:

• Residential Solar Systems: Efficiently manages solar power for homes, ensuring optimal energy storage and use.
• Off-Grid Installations: Perfect for remote cabins, tiny homes, and standalone systems requiring reliable energy management.
• Commercial Solar Systems: Scalable and flexible for larger installations with higher energy demands.
• Mobile and Marine Applications: Reliable solar power management for RVs, boats, and campervans.

Technical Specifications:

Specification	Details
Model Number	SCC115060211
Battery Voltage	12V / 24V / 48V Auto Select (36V selectable)
Rated Charge Current	60A
Nominal PV Power (12V System)	860W
Nominal PV Power (24V System)	1720W
Nominal PV Power (48V System)	3440W
Maximum PV Open Circuit Voltage	150V (absolute max); 145V (operating max)
Peak Efficiency	98%
Self-Consumption	< 35mA @ 12V / < 20mA @ 48V
Battery Charging Stages	Bulk, Absorption, Float
Operating Temperature Range	-30°C to +60°C (-22°F to +140°F)
Full Output Temperature Range	Up to 40°C (derates beyond this temperature)
Protection Rating	IP43 (electronics), IP22 (connection area)
Communication Ports	Bluetooth, VE.Direct
Dimensions (H x W x D)	185 x 250 x 95 mm (7.3 x 9.8 x 3.7 inches)
Weight	3 kg (6.6 lbs)
Certifications	CE, RoHS, IEC 62109

Why Choose the SmartSolar MPPT 150/60-Tr?

1. Efficiency: Industry-leading 98% peak efficiency ensures minimal energy loss.
2. Flexibility: Compatible with multiple battery voltages and solar configurations.
3. Convenience: Built-in Bluetooth for wireless monitoring and configuration.
4. Safety: Comprehensive protection features safeguard your system and components.
5. Reliability: Robust design and advanced recovery functions for long-term performance.

The Victron Energy SmartSolar MPPT 150/60-Tr Charge Controller is a versatile and efficient solution for modern solar energy systems. Its advanced technology, user-friendly design, and extensive protection features make it the ideal choice for maximizing energy output and maintaining battery health across various applications.
