Description
Introducing the Victron Energy SmartSolar MPPT 75/15 Charge Controller (Model SCC075015060R)—an advanced, high-efficiency solar charge controller designed to optimize energy harvest and protect your batteries. Equipped with cutting-edge MPPT technology and seamless Bluetooth connectivity, this controller is an ideal solution for both small-scale residential and commercial solar energy systems.
Key Features:
- Ultra-Fast MPPT Technology: Enhances energy harvest by up to 30%, ensuring maximum power extraction even under cloudy or variable light conditions.
- Built-in Bluetooth Connectivity: Monitor and configure your solar system in real-time via the VictronConnect app on your smartphone, tablet, or computer.
- Automatic Voltage Recognition: Simplifies installation by automatically detecting 12V or 24V battery systems for seamless integration.
- Intelligent Load Management: Protects your battery from over-discharge by disconnecting non-critical loads, prolonging battery lifespan and ensuring reliable system operation.
- High Efficiency: Achieves peak efficiency of up to 98%, minimizing energy loss during conversion and maximizing battery charge.
- Fully Programmable Settings: Customizable charging algorithms for a wide range of battery types, including AGM, GEL, Flooded, and Lithium (LiFePO‚ÇÑ).
- Compact and Lightweight Design: Space-saving form factor for easy installation in diverse applications.
- Comprehensive Protections: Safeguards against reverse polarity, short circuits, overheating, and reverse current, ensuring long-term reliability.
Product Overview:
The Victron Energy SmartSolar MPPT 75/15 is engineered to efficiently convert energy from your solar panels into usable power for your batteries. Using ultra-fast MPPT technology, the controller continuously adjusts to the ideal operating point, significantly improving energy harvest compared to traditional PWM charge controllers.
The integrated Bluetooth functionality offers wireless control and monitoring via the VictronConnect app, allowing users to access real-time system performance, adjust settings, and view historical data for enhanced system management.
The intelligent load output feature provides additional protection for your batteries by automatically disconnecting loads when battery voltage drops to critical levels. This ensures that your energy storage system remains functional and protected, even during high-demand or low-energy scenarios.
With a fully programmable charging algorithm, the SmartSolar 75/15 can be customized to suit the specific requirements of various battery types, optimizing performance and extending battery life. Its compact design, low self-consumption, and comprehensive protection features make it a reliable choice for small solar energy systems.
Applications:
- Residential Solar Systems: Supports small-scale home solar setups for efficient energy management.
- Off-Grid Systems: Ideal for cabins, tiny homes, and other remote installations.
- Mobile Solar Systems: Perfect for RVs, campervans, and boats requiring reliable battery charging.
- Industrial Use: Suitable for powering remote monitoring stations, telecommunications equipment, and other small industrial systems.
Technical Specifications:
| Specification | Details |
|---|---|
| Model Number | SCC075015060R |
| Battery Voltage (Auto Select) | 12V / 24V |
| Rated Charge Current | 15A |
| Nominal PV Power (12V System) | 220W |
| Nominal PV Power (24V System) | 440W |
| Max. PV Open Circuit Voltage | 75V |
| Peak Efficiency | 98% |
| Self-Consumption (Load On) | 12V: 19mA / 24V: 16mA |
| Self-Consumption (Load Off) | 12V: 10mA / 24V: 8mA |
| Battery Charging Stages | Bulk, Absorption, Float |
| Operating Temperature Range | -30°C to +60°C (-22°F to +140°F) |
| Full Output Temperature Range | Up to 40°C (derates beyond this temperature) |
| Protection Rating | IP43 (electronics), IP22 (connections) |
| Communication Ports | Bluetooth, VE.Direct |
| Dimensions (H x W x D) | 100 x 113 x 40 mm (3.9 x 4.4 x 1.6 inches) |
| Weight | 0.5 kg (1.1 lbs) |
| Certifications | CE, RoHS, IEC 62109 |
Why Choose the SmartSolar MPPT 75/15?
- Efficiency: Industry-leading 98% peak efficiency for minimal energy loss.
- Convenience: Built-in Bluetooth for real-time monitoring and easy configuration.
- Versatility: Supports a wide range of battery types and solar setups.
- Protection: Advanced electronic safeguards ensure long-lasting system reliability.
- Compact Design: Space-saving form factor ideal for mobile and off-grid installations.
The Victron Energy SmartSolar MPPT 75/15 Charge Controller is a high-performance, reliable, and user-friendly device that ensures maximum energy efficiency and system longevity. Whether you're powering a home, a boat, or an industrial system, this controller is the perfect addition to your solar energy setup.
