Victron Energy Orion IP67 24/12-100A 1200W | DC-DC Converter

The Victron Energy Orion IP67 24/12-100A is a fully encapsulated, non-isolated DC-to-DC converter stepping down a 24V input to a stable 12V output at up to 100A continuous — delivering up to 1200W of converted power for 12V loads and equipment in marine, automotive, RV, and industrial applications.

Built into a cast aluminium enclosure with resin-moulded electronics, the Orion IP67 24/12-100A is fully waterproof, shockproof, and ignition protected, making it suitable for permanent installation in bilges, engine rooms, machine rooms, and other harsh environments where exposure to water, oil, and dirt is a regular concern.

At the top of the 24V-to-12V Orion IP67 range, the 24/12-100A uses M6 bolt DC connections to handle the substantial cable requirements of a 100A 12V output, accommodating the heavy gauge wiring necessary for high-current installations.

Key Features:

• IP67 Fully Waterproof Enclosure — Cast aluminium housing with resin-moulded electronics is fully waterproof, shockproof, and ignition protected; water, oil, and dirt will not damage the converter — suitable for bilge, engine room, and machine room permanent installations
• 100A Continuous 12V Output — Delivers up to 100A continuous output current at 12V ±3% from an 18–35V input, providing stable high-current 12V power for large loads in 24V source systems with full rated output maintained up to 40°C ambient
• M6 Bolt DC Connections — Heavy-duty M6 bolt input and output connections accommodate the large cable cross-sections required for 100A continuous current; unlike the smaller Orion IP67 models, the 24/12-100A does not use pre-terminated cables — installer-supplied cabling is required
• 96% Efficiency with Overheating Protection — Industry-leading 96% conversion efficiency minimizes heat generation and power loss at high continuous current; output current derates automatically at 3% per °C above 40°C, allowing safe operation in hot environments up to 70°C without shutdown
• Wide 18–35V Input Voltage Range — Accommodates the full operating voltage range of 24V lead-acid and lithium battery systems including charging voltage peaks and surges from other equipment connected to the same battery, ensuring stable 12V output throughout the entire 24V battery charge and discharge cycle
• Hiccup Mode Overload Protection — Automatically enters hiccup mode under overload conditions and recovers without intervention once the fault condition is removed; fully short circuit proof

The Orion IP67 24/12-100A operates across an 18–35V input voltage range with under-voltage shutdown at 15V and restart at 16V, protecting the 24V source from deep discharge during conversion operations. No-load current draw at 24V is 85mA — slightly higher than the smaller models in the range due to the unit's larger internal circuitry — but remains low enough to avoid significant parasitic drain on the 24V source battery when no 12V load is connected. Output ripple and noise is 150mVpp, shared with the 12/24-50A model. As a non-isolated converter, input and output share a common ground — an important distinction when planning system wiring in applications where ground separation between source and load circuits is required; for those applications, the Orion-Tr isolated DC-DC converter range is recommended instead. Reverse polarity protection requires an external fuse or circuit breaker on the input side; this protection is not built into the unit and must be provided by the installer.
