Description
Key Features
- Pure Sine Wave Output: Delivers 120V AC power, ensuring compatibility with sensitive electronics.
- PowerControl & PowerAssist: Manages generator or grid power, supplementing with battery power during peak demands.
- Dual AC Outputs: Provides uninterrupted power to essential loads and a secondary output for non-essential loads.
- Remote Monitoring: Compatible with Victron's GX devices for system monitoring and control via the VRM portal.
- Scalable Design: Supports parallel and three-phase configurations for expanded power needs.
Product Overview
The Victron Energy MultiPlus-II 24V 5000VA 95A 120V Inverter & Charger is a versatile solution for off-grid, marine, and backup power applications. Combining a powerful inverter with a sophisticated battery charger, it ensures reliable power delivery and efficient energy management.
Its PowerControl and PowerAssist features allow for intelligent power management, preventing overloads by supplementing power from the battery when needed. The dual AC outputs ensure that critical loads remain powered during outages, while non-essential loads are managed appropriately.
Designed for scalability, the MultiPlus-II can be configured in parallel or three-phase setups, accommodating growing power requirements. Remote monitoring capabilities via Victron's GX devices and the VRM portal provide users with real-time insights and control over their power systems.
Technical Specifications
| Specification | Details |
|---|---|
| Model | MultiPlus-II 24/5000/120-95 |
| Inverter Continuous Output | 5000 VA / 4000 W at 25°C |
| Peak Power | 9000 W |
| Battery Voltage | 24 V DC |
| Charger Output | 95 A |
| AC Output Voltage | 120 V ±2% |
| Frequency | 60 Hz ±0.1% |
| Transfer Switch | 95 A |
| AC Inputs | 1 |
| AC Outputs | 2 (Main and Auxiliary) |
| DC Input Voltage Range | 19 – 33 V |
| Efficiency | Up to 96% |
| Dimensions (HxWxD) | 24.7 x 13.8 x 5.9 inches |
| Weight64 | 64 lbs |
| Protection Rating | IP22 |
| Operating Temperature | -40°C to +65°C |
| Certifications | UL 1741, CSA C22.2 |
| Warranty | 5 Years |
