Description
Introducing the Victron Energy BlueSolar PWM-Light Charge Controller 12/24V-10A (Model: SCC010010000), a reliable and efficient solution for managing your solar energy system. Designed to optimize battery charging and protect your system components, this charge controller is ideal for both 12V and 24V setups.
Key Features:
- Automatic System Voltage Detection: Seamlessly detects and adapts to 12V or 24V systems, ensuring compatibility and ease of installation.
- Three-Stage Battery Charging: Implements bulk, absorption, and float charging stages to enhance battery performance and longevity.
- Integrated Lighting Control: Features a programmable load output with a single timer, perfect for managing lighting systems based on time or light conditions.
- Comprehensive Protection Mechanisms: Safeguards against overcurrent, short circuits, reverse polarity connections, and low battery voltage, ensuring the durability and safety of your solar setup.
- User-Friendly Interface: Equipped with a two-digit, seven-segment display for straightforward configuration and monitoring of load output functions, including timer settings.
Product Overview:
The Victron Energy BlueSolar PWM-Light Charge Controller is engineered to efficiently manage the energy harvested from your solar panels, directing it to your batteries while preventing overcharging and excessive discharging. Its automatic voltage recognition simplifies setup, making it suitable for both novice and experienced users.
The three-stage charging process begins with the bulk stage, delivering maximum current until the battery reaches a set voltage. It then transitions to the absorption stage, maintaining this voltage to fully charge the battery without overcharging. Finally, the float stage keeps the battery at a safe voltage, ready for use.
This model's integrated lighting control function is particularly beneficial for solar lighting applications. The programmable timer allows you to set precise on/off times, ensuring efficient energy use and extending battery life.
Safety is a paramount concern with the BlueSolar PWM-Light Charge Controller. It offers multiple protection features, including safeguards against overcurrent and short circuits, as well as reverse polarity protection for both the battery and solar array. Additionally, the low voltage disconnect function prevents battery damage by disconnecting the load when the battery is depleted, automatically reconnecting when the battery is sufficiently recharged.
The intuitive two-digit display simplifies the process of setting and adjusting parameters, making system management accessible and efficient. Whether you're setting up a new solar installation or upgrading an existing one, the Victron Energy BlueSolar PWM-Light Charge Controller 12/24V-10A offers a blend of functionality, protection, and user-friendliness to meet your energy management needs.
Technical Specifications:
Specification | Details |
---|---|
Model Number | SCC010010000 |
Battery Voltage | 12/24V with automatic system voltage detection |
Rated Charge Current | 10A |
Recommended Solar Array | 36-cell for 12V / 72-cell for 24V systems |
Maximum Solar Voltage | 28V for 12V systems / 55V for 24V systems |
Self-Consumption | <10 mA |
Charge Voltage (Absorption) | 14.2V / 28.4V |
Charge Voltage (Float) | 13.8V / 27.6V |
Low Voltage Load Disconnect | 11.2V / 22.4V |
Low Voltage Load Reconnect | 12.6V / 25.2V (manual) / 13.1V / 26.2V (automatic) |
Operating Temperature Range | -20°C to +50°C (full load) |
Humidity (Non-Condensing) | Max 95% |
Protection Class | IP20 |
Dimensions (H x W x D) | 70 x 133 x 33.5 mm (2.8 x 5.3 x 1.3 inches) |
Weight | 0.13 kg |
