Description
Introducing the Victron Energy BlueSolar MPPT 100/50 Charge Controller (Model: SCC020050200)—an advanced solar energy management device designed to maximize energy harvest and ensure safe and efficient battery charging for 12V and 24V systems. Ideal for residential, commercial, and off-grid solar installations, this charge controller combines ultra-fast MPPT technology with a robust design to deliver superior performance.
Key Features:
- Ultra-Fast Maximum Power Point Tracking (MPPT): Rapidly tracks the optimal power point of solar panels, improving energy harvest by up to 30% compared to traditional PWM charge controllers.
- Automatic Battery Voltage Detection: Seamlessly adapts to 12V or 24V battery systems, simplifying installation and ensuring broad compatibility.
- High Conversion Efficiency: Operates with a peak efficiency of up to 98%, minimizing energy loss during the charging process.
- Robust Protections: Includes safeguards against over-temperature, PV reverse polarity, and output short circuits, ensuring reliable operation and system safety.
- Real-Time Monitoring and Control: Compatible with the VictronConnect App via the VE.Direct port, enabling real-time system monitoring, configuration, and performance tracking.
- Adaptive Charging Algorithm: Offers a multi-stage adaptive charging process (bulk, absorption, float), ensuring optimal battery performance and lifespan.
- Wide PV Input Range: Handles PV open circuit voltages up to 100V, supporting diverse solar panel configurations.
Product Overview:
The BlueSolar MPPT 100/50 Charge Controller is engineered for efficiency and reliability, ensuring your solar energy system operates at peak performance even under challenging conditions such as partial shading or rapidly changing light intensity. Its ultra-fast MPPT technology dynamically adjusts to maximize energy capture, making it an ideal choice for maximizing power output in both residential and commercial solar applications.
The controller is designed to automatically detect 12V or 24V battery systems, streamlining installation and reducing the need for manual configuration. It supports a maximum PV open circuit voltage of 100V and a rated charge current of 50A, making it suitable for powering a variety of loads, from residential batteries to off-grid solar setups.
With its high efficiency of 98%, the BlueSolar MPPT 100/50 minimizes energy loss, ensuring that more power is directed to your batteries. The multi-stage adaptive charging algorithm ensures batteries are charged optimally, preventing overcharging and undercharging, both of which can shorten battery life.
Safety is a top priority in the design of this charge controller. It includes protections against PV reverse polarity, over-temperature, and output short circuits, ensuring the safety of your solar power system and its components.
For advanced users, the VE.Direct communication port allows seamless integration with the VictronConnect App, enabling real-time monitoring, configuration, and historical data analysis. This feature makes it easy to track energy performance, optimize system settings, and troubleshoot issues remotely.
Applications:
- Residential Solar Systems: Efficiently powers home battery setups, ensuring reliable energy management.
- Commercial Solar Installations: Suitable for medium-scale systems requiring robust energy harvesting capabilities.
- Off-Grid Systems: Ideal for powering remote locations, cabins, and standalone energy systems.
- Mobile Solar Systems: Perfect for RVs, boats, and other mobile platforms requiring dependable solar power.
Technical Specifications:
| Specification | Details |
|---|---|
| Model Number | SCC020050200 |
| Battery Voltage | 12V / 24V Auto Select |
| Maximum Charge Current | 50A |
| Nominal PV Power (12V System) | 700W |
| Nominal PV Power (24V System) | 1400W |
| Maximum PV Open Circuit Voltage | 100V |
| Peak Efficiency | 98% |
| Charge Algorithm | Multi-stage adaptive or user-defined |
| Self-Consumption | 12V: 30mA / 24V: 20mA |
| Operating Temperature Range | -30°C to +60°C (-22°F to +140°F) |
| Full Output Temperature Range | Up to 40°C (derates beyond 40°C) |
| Protection Rating | IP43 (electronics), IP22 (connection area) |
| Communication Ports | VE.Direct |
| Dimensions (H x W x D) | 130 x 186 x 70 mm (5.1 x 7.3 x 2.8 in) |
| Weight | 1.3 kg (2.87 lbs) |
| Certifications | CE, RoHS, IEC 62109 |
| Warranty | 5 Years |
Why Choose the Victron BlueSolar MPPT 100/50?
- Efficiency: Industry-leading 98% efficiency ensures minimal energy loss and optimal charging performance.
- Convenience: Automatic battery voltage recognition and real-time monitoring simplify installation and system management.
- Flexibility: Supports various solar panel configurations and battery chemistries.
- Safety: Comprehensive electronic protections safeguard your system from operational hazards.
- Reliability: Designed for harsh environments, ensuring consistent performance in diverse applications.
The Victron Energy BlueSolar MPPT 100/50 Charge Controller is a robust and efficient choice for anyone looking to maximize the energy yield and reliability of their solar energy system. Whether for residential, off-grid, or mobile applications, this charge controller delivers exceptional performance, making it a valuable addition to any solar power setup.
