Description
The Victron Energy Quattro 12/5000/220-100/100 120V Inverter/Charger is a versatile and robust solution for your power management needs. Combining a powerful 5,000W pure sine wave inverter with an adaptive 200A battery charger, it ensures seamless and reliable energy supply for various applications, including off-grid systems, mobile installations, and backup power setups.
Key Features:
- Dual AC Inputs with Automatic Transfer Switch: Connects to two independent AC sources, such as shore power and a generator, automatically selecting the active source to ensure uninterrupted power supply.
- PowerAssist Technology: Prevents overload of limited AC sources by supplementing power from the battery during peak demand, ensuring continuous operation without tripping breakers or overloading generators.
- Parallel and Three-Phase Operation: Supports parallel operation of up to six units for higher power output and can be configured for three-phase or split-phase setups, offering flexibility for diverse power requirements.
- Uninterrupted Power Supply (UPS) Functionality: In the event of a grid failure or disconnection of shore or generator power, the Quattro seamlessly takes over the supply to connected loads within 20 milliseconds, ensuring critical equipment continues to operate without disruption.
- Remote Monitoring and Control: When paired with a GX device (e.g., Cerbo GX), monitor and control your system locally or remotely via the internet using the free VRM app and portal, providing access from any device, anywhere.
The Quattro's dual AC inputs allow for connection to two independent AC sources, such as shore power and a generator. It automatically selects the active source, ensuring a reliable power supply. The main output features a no-break functionality; in the event of a grid failure or disconnection, the Quattro takes over the supply to connected loads within 20 milliseconds, ensuring uninterrupted operation of sensitive equipment.
The unique PowerAssist feature prevents overload of limited AC sources by first reducing battery charging when an overload is imminent. If necessary, it boosts the output with power taken from the battery, ensuring continuous operation without overloading the source.
For systems requiring higher power output, up to six Quattros can operate in parallel. Additionally, three units can be configured for three-phase or split-phase operation, providing flexibility to meet diverse power needs.
Remote monitoring and control are facilitated when the Quattro is coupled with a GX device, such as the Cerbo GX. This setup allows users to monitor and control their system locally or remotely via the internet, using the free VRM app and portal, accessible from any device.
Specifications:
Specification | Details |
---|---|
Inverter Continuous Output | 5,000 VA |
DC Input Voltage | 12 V |
AC Output Voltage | 120 V |
Battery Charger Current | 200 A |
Transfer Switch Rating | 2 x 100 A |
Dimensions (H x W x D) | 18.5 x 14 x 11.2 inches |
Weight | 75 lbs |
Parallel Operation | Up to 6 units |
Three-Phase Operation | Supported |
Remote Monitoring | Via GX device and VRM portal |
