Talesun Bistar 395W 144 Half Cell 9BB Half-Cut Mono Perc

Key Features

• High‑Efficiency 395 W Output: Harness top performance with up to 20.6 % conversion efficiency, maximizing energy yield.
• 9‑Busbar Half‑Cut Mono PERC Cell Tech: Reduces internal resistance, minimizes hotspots, and enhances reliability.
• Rugged & Weather‑Resistant: Built with IP68-rated junction box, anodized aluminum frame, and tempered glass to endure harsh environments.
• Comprehensive Warranty Protection: Backed by a 12-year product warranty and a 25-year linear power output guarantee.
• Cost-Saving Performance: Engineered to produce ~2 % more power and lower the Levelized Cost of Energy (LCOE) over its lifespan.

Product Description

The Talesun BISTAR TP6F72M is a premium-grade 395 W solar module featuring 144 half-cut mono PERC cells arranged with advanced 9-busbar design. This technology lowers resistive losses and mitigates hotspot risk, delivering solid, reliable output even under challenging conditions.

Crafted for longevity, the panel is sealed within a robust anodized aluminum frame and equipped with an IP68-rated junction box—ensuring superior waterproofing and resistance against dust and corrosion. Ideal for residential rooftops, commercial arrays, or off-grid systems, this module offers strong performance in both sunlight and shaded scenarios.

Talesun is a globally recognized Tier-1 solar manufacturer, certified by IEC 61215, IEC 61730, UL 1703, ISO 9001, ISO 14001, and ISO 45001 standards. The BISTAR series highlights Talesun’s dedication to quality, with excellent anti-PID performance—tested at twice the industry standard.

Why Choose the TP6F72M?

1. Maximized Energy Yield – High-efficiency cells and positive power tolerance (0 to +3%) mean more clean energy per panel.
2. Built to Last – Tempered glass, durable frame, and high-integrity junction box deliver decades of trouble-free operation.
3. Future‑Proof Investment – Long-term warranties and reduced energy costs provide peace of mind and ROI.
4. Engineered for Real‑World Conditions – Low temperature coefficients ensure stable power even in extreme heat or cold.

Applications

• Residential rooftop systems
• Commercial solar farms
• Off-grid power applications (e.g., rural electrification, agricultural use)
• RV, marine, and mobile solar setups

Specifications

Parameter	TP6F72M‑395 W
Max Power (P<sub>max</sub>)	395 W (+3% tolerance)
Max Efficiency	20.6 %
Operating Voltage (V<sub>mpp</sub>)	~40.3 V
Operating Current (I<sub>mpp</sub>)	~9.81 A
Open-Circuit Voltage (V<sub>oc</sub>)	48.9 V
Short-Circuit Current (I<sub>sc</sub>)	10.35 A
Cell Type	Monocrystalline PERC
Cell Configuration	144 half-cut, 9-busbar
Dimensions (L×W×H)	2008 × 1002 × 35 mm
Weight	22.5 kg
Frame	Anodized aluminum
Junction Box	IP68, MC4 compatible
Cable Length	300 mm (portrait) / 1200 mm (landscape)
Temperature Coefficients	P: ‑0.36 %/°C, Voc: ‑0.26 %/°C, Isc: +0.043 %/°C
Max System Voltage	1000 / 1500 V DC
Operating Temp Range	‑40 °C to +85 °C
Warranty	12 yr product, 25 yr linear power
