Description
Key Features
- High‑Efficiency 395 W Output: Harness top performance with up to 20.6 % conversion efficiency, maximizing energy yield.
- 9‑Busbar Half‑Cut Mono PERC Cell Tech: Reduces internal resistance, minimizes hotspots, and enhances reliability.
- Rugged & Weather‑Resistant: Built with IP68-rated junction box, anodized aluminum frame, and tempered glass to endure harsh environments.
- Comprehensive Warranty Protection: Backed by a 12-year product warranty and a 25-year linear power output guarantee.
- Cost-Saving Performance: Engineered to produce ~2 % more power and lower the Levelized Cost of Energy (LCOE) over its lifespan.
Product Description
The Talesun BISTAR TP6F72M is a premium-grade 395 W solar module featuring 144 half-cut mono PERC cells arranged with advanced 9-busbar design. This technology lowers resistive losses and mitigates hotspot risk, delivering solid, reliable output even under challenging conditions.
Crafted for longevity, the panel is sealed within a robust anodized aluminum frame and equipped with an IP68-rated junction box—ensuring superior waterproofing and resistance against dust and corrosion. Ideal for residential rooftops, commercial arrays, or off-grid systems, this module offers strong performance in both sunlight and shaded scenarios.
Talesun is a globally recognized Tier-1 solar manufacturer, certified by IEC 61215, IEC 61730, UL 1703, ISO 9001, ISO 14001, and ISO 45001 standards. The BISTAR series highlights Talesun’s dedication to quality, with excellent anti-PID performance—tested at twice the industry standard.
Why Choose the TP6F72M?
- Maximized Energy Yield – High-efficiency cells and positive power tolerance (0 to +3%) mean more clean energy per panel.
- Built to Last – Tempered glass, durable frame, and high-integrity junction box deliver decades of trouble-free operation.
- Future‑Proof Investment – Long-term warranties and reduced energy costs provide peace of mind and ROI.
- Engineered for Real‑World Conditions – Low temperature coefficients ensure stable power even in extreme heat or cold.
Applications
- Residential rooftop systems
- Commercial solar farms
- Off-grid power applications (e.g., rural electrification, agricultural use)
- RV, marine, and mobile solar setups
Specifications
| Parameter | TP6F72M‑395 W |
|---|---|
| Max Power (P<sub>max</sub>) | 395 W (+3% tolerance) |
| Max Efficiency | 20.6 % |
| Operating Voltage (V<sub>mpp</sub>) | ~40.3 V |
| Operating Current (I<sub>mpp</sub>) | ~9.81 A |
| Open-Circuit Voltage (V<sub>oc</sub>) | 48.9 V |
| Short-Circuit Current (I<sub>sc</sub>) | 10.35 A |
| Cell Type | Monocrystalline PERC |
| Cell Configuration | 144 half-cut, 9-busbar |
| Dimensions (L×W×H) | 2008 × 1002 × 35 mm |
| Weight | 22.5 kg |
| Frame | Anodized aluminum |
| Junction Box | IP68, MC4 compatible |
| Cable Length | 300 mm (portrait) / 1200 mm (landscape) |
| Temperature Coefficients | P: ‑0.36 %/°C, Voc: ‑0.26 %/°C, Isc: +0.043 %/°C |
| Max System Voltage | 1000 / 1500 V DC |
| Operating Temp Range | ‑40 °C to +85 °C |
| Warranty | 12 yr product, 25 yr linear power |
