Description
SLD Tech (Solarland) ST-120P-12 120-Watt Monocrystalline Solar Panel
Introducing the SLD Tech ST-120P-12, a 120-watt monocrystalline solar panel engineered for optimal performance in 12V off-grid applications. Whether you're powering a remote cabin, RV, boat, or any standalone system, this panel delivers reliable and efficient energy conversion to meet your needs.
Key Features:
- High Efficiency: Utilizes monocrystalline cells with a module efficiency of 20%, ensuring maximum energy capture even in low-light conditions.
- Durable Construction: Built with a heavy-duty anodized aluminum frame and high-transparency, low-iron tempered glass, this panel withstands high wind pressures, hail, and heavy snow loads.
- Standard 12V Output: Provides a nominal 12V DC output, making it compatible with a wide range of off-grid systems and battery configurations.
- Compact Design: Incorporating 32 monocrystalline cells, the panel offers a balance between size and power output, ideal for installations with limited space.
- Aesthetic Appeal: The silver frame and white backsheet provide a clean, professional look, enhancing the visual appeal of your solar installation.
- Pre-Drilled Mounting Holes: Facilitates quick and hassle-free installation, compatible with standard Z-brackets, pole mounts, and tilt mounts.
- Weatherproof Junction Box: Rated IP65 for resistance to water and dust, ensuring reliable operation in outdoor environments.
Product Overview:
The SLD Tech ST-120P-12 solar panel is crafted to meet the demands of various off-grid applications. Its high-efficiency monocrystalline cells ensure optimal energy production, even during overcast days or in shaded environments. The robust construction, featuring a heavy-duty anodized aluminum frame and tempered glass, guarantees longevity and resilience against environmental challenges.
This panel's nominal 12V DC output is ideal for charging 12V battery systems, commonly used in RVs, boats, and remote power setups. Its compact design, incorporating 32 cells, allows for flexible installation options without compromising power output.
The silver frame combined with the white backsheet offers a sleek and modern look, ensuring that your solar setup is both functional and visually appealing.
Applications:
- Off-grid cabins and homes
- Recreational vehicles (RVs) and motorhomes
- Marine vessels and boats
- Remote monitoring systems
- Emergency backup power systems
Technical Specifications:
| Specification | Details |
|---|---|
| Maximum Power (Pmax) | 120 Watts |
| Module Efficiency | 20% |
| Cell Type | Monocrystalline |
| Number of Cells | 32 |
| Nominal Voltage | 12V DC |
| Voltage at Pmax (Vmp) | 18.6 Volts |
| Current at Pmax (Imp) | 6.45 Amps |
| Open-Circuit Voltage (Voc) | 22.4 Volts |
| Short-Circuit Current (Isc) | 6.91 Amps |
| Dimensions (L x W x H) | 37.40" x 27.76" x 1.38" (950mm x 705mm x 35mm) |
| Weight | 17 lbs (7.7 kg) |
| Frame Material | Anodized Aluminum |
| Glass Type | Low-Iron Tempered Glass |
| Operating Temperature Range | -40°F to 185°F (-40°C to 85°C) |
| Maximum System Voltage | 600V DC |
| Power Tolerance | ±5% |
| Junction Box Rating | IP65 (Water and Dust Resistant) |
| Connector Type | MC4 Compatible |
| Cable Length | 35.4 inches (900mm) |
| Wind Load Resistance | Up to 2400 Pa |
| Snow Load Resistance | Up to 5400 Pa |
| Certifications | CE, TUV, RoHS |
| Warranty | 25-Year Limited Power Output Warranty |
Additional Features:
- PID Resistance: Minimizes degradation over time, ensuring consistent performance.
- Salt Mist and Ammonia Resistance: Suitable for coastal and agricultural installations.
- Enhanced Low-Light Performance: Maintains output during cloudy or shaded conditions.
- Temperature Coefficient: High efficiency in extreme temperature variations, suitable for diverse climates.
- Easy Maintenance: Anti-reflective, self-cleaning glass reduces dust and dirt accumulation for sustained energy output.
The SLD Tech ST-120P-12 120-Watt Monocrystalline Solar Panel combines reliability, efficiency, and durability, making it an exceptional choice for various off-grid energy solutions. Its robust design and advanced features ensure long-term performance in challenging environments.
