Secure your solar panel installations with the IntegraRack Concrete Slab/Footing Anchor Bolt Mounting Kit, designed for robust and reliable attachment of IntegraRack BallastRack™ systems to concrete surfaces. This comprehensive kit ensures that your solar modules remain firmly in place, providing peace of mind and enhanced durability for your solar energy setup.

Key Features:

• Comprehensive Kit for Up to 10 Solar Modules: Each kit includes all necessary components to securely mount up to ten solar modules, streamlining the installation process.High-Quality Concrete Anchor Bolts: The kit features strong concrete anchor bolts designed for maximum holding power, ensuring stability even in challenging conditions.

• Includes Specialized Drill Bits: Two high-quality concrete drill bits are provided, tailored for precise and efficient drilling into concrete surfaces.

• Versatile Application: Suitable for direct bolting to pre-cast concrete slabs, footings, or existing concrete surfaces like patios, offering flexibility in installation locations.

• Enhanced Wind Resistance: When properly installed, the kit provides superior wind resistance, safeguarding your solar modules against high wind conditions.

Product Overview:

The IntegraRack Concrete Slab/Footing Anchor Bolt Mounting Kit is meticulously designed to facilitate the secure attachment of IntegraRack BallastRack™ systems—such as the IR-15, IR-30, IR-45, IR-35A, and IR-45ASA models—to concrete surfaces. This kit is ideal for installations on pre-cast concrete footings or existing concrete areas, including patios, where site-specific engineering confirms suitability.

Included Components:

• 22 Concrete Tapcon Bolts with Washers
• 2 Specialized Concrete Drill Bits
• 1 High-Quality Open-Ended Ratchet Wrenchs

These components are crafted to ensure a seamless installation process, providing installers with the tools needed for efficient and secure mounting.

Installation Process:

Installing the IntegraRack Concrete Slab/Footing Anchor Bolt Mounting Kit is straightforward:

1. Frame Assembly: Begin by assembling the IntegraRack BallastRack™ frames according to the specific model's instructions.
2. Site Preparation: Position the assembled frames on the designated concrete surface, ensuring alignment with the planned layout.
3. Drilling: Utilize the provided concrete drill bits to create precise holes in the concrete at marked locations.
4. Anchoring: Insert the concrete Tapcon bolts through the frame bases into the drilled holes, securing them tightly using the included ratchet wrench.
5. Final Adjustments: After securing all bolts, perform a thorough inspection to confirm the stability and alignment of the frames before mounting the solar modules.

This methodical approach ensures a secure and durable installation, optimizing the performance and longevity of your solar energy system.

Compatibility:

The mounting kit is compatible with the following IntegraRack BallastRack™ models:

• IR-15
• IR-30
• IR-45
• IR-35A
• IR-45ASA

This compatibility ensures that regardless of the specific BallastRack™ system in use, the mounting kit provides a secure anchoring solution.

Technical Specifications:

Specification	Details
Model Number/ID	IR-RFCB1074
Compatible Rack Frames	IR-15, IR-30, IR-45, IR-35A, IR-45ASA
Number of Anchor Bolts	22
Anchor Bolt Type	Concrete Tapcon Bolts
Number of Washers	22
Number of Drill Bits	2
Drill Bit Material	High-Quality Steel
Included Tools	Open-Ended Ratchet Wrench
Installation Surface	Pre-cast concrete slabs, footings, existing concrete surfaces (e.g., patios)
Wind Load Resistance	Up to 200 mph (depending on specific BallastRack™ model and installation conditions)
Snow Load Resistance	Up to 100 psf (depending on specific BallastRack™ model and installation conditions)
Weight of Kit	Approximately 5 lbs
Package Dimensions	8 × 4 × 4 inches
UPC	85582600046
