Description
The EG4 WallMount Indoor 100Ah Lithium Battery is designed for residential and light commercial energy storage systems that require reliable performance, safety, and scalability in a compact format. This 48V 5.12kWh battery uses advanced LiFePO₄ (Lithium Iron Phosphate) chemistry and is optimized for wall-mounted indoor applications. It offers long cycle life, a built-in Battery Management System (BMS), and plug-and-play scalability with other EG4 components. Whether you’re building a new solar-plus-storage system or expanding an existing one, this battery offers a dependable and space-efficient solution for long-term energy independence.
Key Features
- High-Efficiency Storage: Delivers 5.12kWh capacity with 48V output for robust off-grid and backup power.
- Built-in BMS: Integrated Battery Management System ensures maximum safety, performance, and lifespan.
- Space-Saving Design: Sleek, wall-mounted enclosure saves floor space and simplifies installation.
- Certified Safety: UL1973 and UL9540A certified for trusted performance and enhanced protection.
- Long Life Span: Over 6,000 cycles at 80% Depth of Discharge (DoD) ensures decades of reliable use.
Product Overview
The EG4 WallMount Indoor 100Ah Lithium Battery is engineered to meet the demands of modern energy storage applications. With a 100A continuous charge/discharge rating, it provides seamless integration with most 48V inverters and solar systems. The battery includes a built-in BMS that protects against over-voltage, under-voltage, over-temperature, and short circuits, maximizing safety and battery health over time.
Its compact, vertical profile allows for clean installations in utility rooms, garages, or mechanical closets. Thanks to the integrated 150A-rated internal busbar and Degson quick-connect terminals, this battery can be easily paralleled with others for increased capacity. Optional accessories like the EG4 conduit box simplify electrical connections, offering a neat and professional installation with minimal external wiring.
Ideal for homeowners, installers, or system integrators looking for an indoor-rated lithium battery with proven reliability, the EG4 WallMount Indoor 100Ah offers a balance of performance, safety, and ease of use.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | EG4LL48V100AHIDWMB |
| Nominal Voltage | 51.2V |
| Capacity | 100Ah |
| Total Energy | 5.12kWh |
| Max Continuous Current | 100A |
| Integrated Busbar | 150A |
| Battery Chemistry | LiFePO₄ (Lithium Iron Phosphate) |
| Cycle Life | >6,000 cycles at 80% DoD |
| Design Life | >15 years |
| Certifications | UL1973, UL9540A |
| Weight | 108 lbs (49 kg) |
| Dimensions (L×W×H) | 7.6 × 17.8 × 23.2 in (193 × 452 × 589 mm) |
| Communication Ports | RS485, CANBus |
| Warranty | 10 Years |
