Description
EG4 Hybrid Solar Mini-Split Air Conditioner/Heat Pump
Introducing the EG4 Hybrid Solar Mini-Split Air Conditioner/Heat Pump—a cutting-edge solution for efficient and eco-friendly climate control. Designed to seamlessly integrate with solar power systems, this 2-ton (24,000 BTU) unit offers superior performance for spaces up to 1,350 square feet. Whether you're aiming to reduce energy costs or enhance your home's sustainability, the EG4 Mini-Split is the ideal choice.
Key Features:
- Hybrid AC/DC Operation: Utilizes both alternating current (AC) from the grid and direct current (DC) from solar panels, ensuring continuous operation and maximizing energy savings.
- Plug-N-Cool Technology: Features an easy DIY installation process with quick-connect self-closing valves, eliminating the need for special tools or professional assistance.
- High Energy Efficiency: Boasts a SEER2 rating of 21, delivering exceptional cooling and heating performance while minimizing energy consumption.
- Wide Operating Temperature Range: Operates effectively in temperatures ranging from -10°C to 58°C, ensuring reliable performance in various climates.
- Solar Integration: Connects directly to solar panels without the need for inverters or batteries, allowing for 100% energy savings during sunny days.
- Eco-Friendly Refrigerant: Uses R410A refrigerant, which is more environmentally friendly compared to older refrigerants.
- Smart Control: Features Wi-Fi connectivity for remote monitoring and control through a dedicated mobile app.
- Ductless Design: Eliminates the need for ductwork, reducing energy loss and making it a versatile solution for various settings.
Product Overview:
The EG4 Hybrid Solar Mini-Split is engineered to provide efficient heating and cooling by harnessing solar energy during the day and seamlessly switching to grid power when needed. Its innovative design eliminates the need for ductwork, making it a versatile solution for various applications, including homes, offices, and off-grid locations.
The unit's Plug-N-Cool technology simplifies installation, allowing homeowners to set up the system without specialized tools or professional assistance. This feature, combined with its high energy efficiency and ability to operate in a wide range of temperatures, makes the EG4 Mini-Split a reliable and cost-effective choice for year-round climate control.
Key Specifications:
Specification | Details |
---|---|
Cooling Capacity | 24,000 BTU/h (2 Ton) |
Heating Capacity | 26,000 BTU/h |
SEER2 Rating | 21 |
Power Supply | 208-240V AC / 90-380V DC |
Recommended Solar Input | 1,600-2,400W (90VDC-380VDC) |
Indoor Unit Dimensions (W×D×H) | 42.5×8.9×13.2 in. (1080×226×335mm) |
Outdoor Unit Dimensions (W×D×H) | 35.4×13.3×27.6 in. (900×340×700mm) |
Indoor Unit Weight | 17.5 kg (38.58 lbs) |
Outdoor Unit Weight | 59.57 kg (131.35 lbs) |
Refrigerant | R410A, pre-charged for up to 16.4 ft line set |
Max Line Set Length | 50 ft (15.24 m) |
Sound Level (Indoor/Outdoor) | 34 dB(A) / 54 dB(A) |
Airflow Rate | 670 CFM |
Operating Temperature Range (Cooling) | -10°C to 58°C (14°F to 136°F) |
Operating Temperature Range (Heating) | -20°C to 24°C (-4°F to 75°F) |
Max Solar Panel Configuration | 6 x 400W panels (approx.) |
Wi-Fi Connectivity | Built-in |
Warranty | 5-Year Limited on Compressor; 3-Year on Parts |
Additional Features:
- Dual Operation Modes: Automatically toggles between solar and grid power for uninterrupted operation.
- Auto-Clean Function: Prevents mold and bacterial buildup by drying the interior of the indoor unit after operation.
- Smart Timer: Customizable schedules for energy-efficient operation.
- Overload Protection: Safeguards against power surges, enhancing system longevity.
- Environmentally Conscious Design: Optimized for reduced carbon footprint with high efficiency and clean energy use.
The EG4 Hybrid Solar Mini-Split Air Conditioner/Heat Pump is the ultimate combination of performance, efficiency, and sustainability. Whether you're looking to reduce energy bills or enhance comfort in your space, this innovative system is a reliable and eco-friendly solution for modern climate control needs.
