Description
Introducing the EG4® LL-S 24V 200Ah Lithium Iron Phosphate Battery, a high-performance energy storage solution designed for reliability and longevity. Engineered with advanced lithium iron phosphate technology, this battery ensures efficient power delivery for various applications.
Key Features:
-
Exceptional Longevity: Designed to exceed 7,000 deep charge and discharge cycles, offering a lifespan of over 15 years at 80% depth of discharge (DoD).
-
Advanced Safety Mechanisms: Equipped with dual on-board fire arrestors and an emergency stop (E-Stop) function for enhanced safety in high-risk environments.
-
Comprehensive Monitoring: Features an on-board LCD touch screen for real-time Battery Management System (BMS) monitoring, providing easy access to critical battery information.
-
Versatile Compatibility: Supports closed-loop communication with various inverters, including EG4, Schneider, Sol-Ark, Victron, Growatt, Megarevo, Luxpower, and Deye, ensuring seamless integration into diverse energy systems.
The EG4® LL-S 48V 100Ah battery is built with 16 UL-listed prismatic 3.2V cells configured in series, delivering a nominal voltage of 51.2V and a capacity of 5.12kWh. Its robust design and high-quality components ensure reliable performance and a 99% operating efficiency.
This battery is UL 1973 certified and conforms to UL 9540A standards, underscoring its commitment to safety and quality. The integrated BMS offers real-time monitoring and protection, safeguarding against overcharge, over-discharge, overcurrent, and temperature anomalies.
For systems requiring higher capacity, up to 64 batteries can be connected in parallel, achieving a substantial 327.6kWh while maintaining BMS communication integrity.
Whether for residential, commercial, or industrial energy storage needs, the EG4® LL-S 48V 100Ah Lithium Iron Phosphate Battery provides a dependable and efficient solution, ensuring consistent power supply and peace of mind.
Specifications:
Parameter | Specification |
---|---|
Nominal Voltage | 25.6V |
Capacity | 200 Ah |
Energy | 5.12kWh |
Cycle Life | >7,000 cycles at 80% DoD |
Communication Interfaces | RS485, CAN |
Dimensions (H×W×D) | 6.1 in × 19 in × 17.4 in (15.5 cm × 48.2 cm × 44.2 cm) |
Weight | 99.6 lbs (45.2 kg) |
Certifications | UL 1973, UL 9540A |
Operating Temperature Range | Charging: 32°F – 113°F (0°C – 45°C) |
Discharging: -4°F – 122°F (-20°C – 50°C) | |
Storage Temperature Range | -4°F – 122°F (-20°C – 50°C) |
Maximum Parallel Connections | Up to 64 modules |
