Description
The Dankoff SunCentric 7325 12V Battery Pump is a high-performance centrifugal pump designed for efficient water transfer in off-grid and remote locations. Powered by a 12-volt battery, this pump is ideal for applications such as irrigation, livestock watering, and domestic water supply.
Key Features:
- High Flow Rate: Capable of delivering up to 29 gallons per minute (GPM) at 5 feet of Total Dynamic Head (TDH), ensuring ample water supply for various needs.
- Efficient Power Consumption: Operates at 111 watts, drawing approximately 7.4 amps, making it suitable for solar-powered systems and minimizing energy usage.
- Durable Construction: Built with a cast iron pump body and glass-filled polycarbonate impeller, offering longevity and resistance to wear.
- Low Maintenance: Designed for minimal upkeep, with motor brushes typically lasting between 5 to 8 years, depending on usage.
Product Description:
The Dankoff SunCentric 7325 12V Battery Pump is engineered to provide reliable water pumping solutions in areas without access to conventional power sources. Its centrifugal design allows for high-volume water movement from shallow sources, with a maximum suction lift of 10 vertical feet at sea level. The pump's robust construction ensures durability, while its efficient power consumption makes it compatible with solar energy systems, promoting sustainable water management.
Installation is straightforward, with the pump requiring protection from direct sunlight and rain. It can be mounted horizontally or vertically, depending on the setup. Regular maintenance is minimal, with easily replaceable motor brushes and a long-lasting shaft seal. This pump is an excellent choice for those seeking a dependable and efficient water pumping solution in off-grid environments.
Specifications:
| Specification | Details |
|---|---|
| Model Number | 7325 |
| Voltage | 12V DC |
| Power Consumption | 111 watts |
| Current Draw | 7.4 amps (8.1 max amps) |
| Flow Rate | 29 GPM at 5' TDH; 16.5 GPM at 10' TDH |
| Total Dynamic Head | Up to 90 feet |
| Suction Lift | 10 vertical feet at sea level (subtract 1 foot per 1,000 ft elevation) |
| Pump Body Material | Cast iron (ASTM A48-76) |
| Impeller Material | Glass-filled polycarbonate |
| Seal Material | Carbon/ceramic |
| Temperature Limit | 140°F (60°C) |
| Weight | 56 lbs |
| Dimensions (L x W x H) | 18" x 12" x 10" |
| Warranty | 2 years against defects in materials and workmanship |
