Grundfos SQ Series 15 GPM 3/4 HP Submersible Well Pump (Model 15SQ07-180)

The Grundfos SQ Series 15 GPM 3/4 HP Submersible Well Pump (Model 15SQ07-180) is engineered to deliver reliable and efficient water supply solutions for residential and small-scale applications. Its compact 3-inch multistage centrifugal design allows for seamless installation in boreholes as small as 3 inches in diameter, ensuring versatility across various setups.

Key Features:

• High Efficiency Permanent Magnet Motor: Equipped with a permanent magnet motor, the pump offers superior efficiency and performance, reducing energy consumption and operational costs.

• Integrated Protection Mechanisms: The pump includes built-in safeguards against dry running, overvoltage, undervoltage, and overload conditions, enhancing durability and extending service life.

• Soft Start Technology: Features a soft start function that minimizes electrical and mechanical stress during startup, reducing the risk of water hammer and prolonging pump longevity.

• Robust Construction: Constructed with stainless steel and polyamide reinforced components, the pump ensures high wear resistance and durability, even in demanding environments.

Designed for both continuous and intermittent operation, the Grundfos 15SQ07-180 is ideal for domestic water supply, small waterworks, irrigation systems, and groundwater lowering applications. Its advanced motor technology not only delivers high performance but also ensures quiet operation, making it suitable for residential settings.

The pump's integrated electronics simplify installation and operation, eliminating the need for external control units. Its compact size and lightweight design facilitate easy handling and installation, even in confined spaces. Additionally, the pump's high starting torque ensures reliable operation, even with low supply voltage, providing consistent water pressure and flow.

With a focus on energy efficiency, reliability, and user-friendly operation, the Grundfos SQ Series 15 GPM 3/4 HP Submersible Well Pump stands out as a dependable choice for ensuring a consistent and efficient water supply.

Key Specifications:

Specification	Details
Model Number	15SQ07-180
Flow Rate	15 GPM
Horsepower	3/4 HP
Voltage	200-240 VAC
Current Draw	8.4 Amps
Discharge Size	1-1/4" NPT
Maximum Head	180 ft
Pump Diameter	3 inches
Motor Type	Permanent Magnet Motor
Protection Features	Dry-running, Over/Undervoltage, Overload
Material	Stainless Steel and Polyamide Reinforced Components
